GPIB24P Male Centronics IEEE488 Connector IDC Crimping Type with Wire Clip

Name: GPIB24P Male Centronics IEEE488 Connector IDC Crimping Type with Wire Clip
Brand: FUYCONN
Price: 0.2 USD

China GPIB24P Male Centronics IEEE488 Connector IDC Crimping Type with Wire Clip wholesale

Brand Name : FUYCONN

Model Number : FUY57151-8

Certification : UL

Place of Origin : China

MOQ : 50pcs

Price : USD0.2-USD2/pc

Payment Terms : T/T, Paypal

Supply Ability : 100000/ week

Delivery Time : 5-8 works day

Packaging Details : Vacuum Tray

Connector Type : IEEE488

Plastic Material : PBT

Contact Material : Phosphore Bronze

Conact Plating : Gold Plating

Shell : Nickeled Plating

No. of Contact : 24 Pin

Wire Cover : PBT & Black

Gender : Male

Contact Now

IEEE488 24 Pin Female IDC Crimping Connector with Wire Cover 2.16mm pitch

centronic 24pin connector IDC Female type

This type of connector got its name from the Centronics Corporation, a manufacturer based in Nashua, New Hampshire. Back in the 1970's, Centronics made printers for use with computers. As computers and attached printers became more popular, the connector that they used became the factoy industry standard. The Centronics Corporation was purchased by Genicom (now TallyGenicom) in the 1980's, but their name lives on in this connector.

The Centronics connector has a plastic bar in the center of the connector body that holds the contact pins. The body of the connector is often black or blue in color.

The Centronics 24-pin connector is arranged in two rows of pins, each with 12 contacts.

Connectors: CN24 Male Connector
IEEE-488 cable is used to connect certain medical equipment
Metal Shell Connector and braid shielding
Type : IEEE-488 GPIB,Product Name :IEEE 488 Cable
Automatic, seamless compatibility between computers and instruments throughout your system

GPIB24P Male Centronics IEEE488 Connector IDC Crimping Type with Wire Clip

Product features

1. Product Line:	Centronic Connector
2. Connector Gender:	Male
4. Number of Position:	24 pin
5. Contact Material: Copper Alloy	Phosphore Bronze
6. Contact Plating:	1U", 3U", 5U", 10U", 15U",30U"
7. Comb Material:	Thermoplastic
8. UL Flammability Rating: UL-94-V0	UL-94-V0
9. Connector Type	IEEE488
10. Shell:	Nickel plated steel
11. Orientation:	Standard

Electrical Specifications

1. Current Rating:	5Amp
2. Voltage rating:	DC 1000v per minute
3. Insulator Resistance:	1000Mn MIN.(at 500V DC)
4. Operation Temperature:	-55°C to +105°C

GPIB24P Male Centronics IEEE488 Connector IDC Crimping Type with Wire Clip

Application

1, VDSL Teleccom Equipment

2, Computer Peripherals

3, Communication Equipment

4, RJ21 Cable

5, Cable to Panel

6, Cable to cable

7,Computer terminal

8,Telemetering

9,Test Equipment

10, Printer

Common Features

Designed for Cable-to-cable and cable-to-PC Board applications

Avilable in Plug & Socket Style

Terminal Option with various types

Connector and hood sold as complete assembly

Avilable in low profile hood style

Metal shell provides grounding and shielding capability

Mates with industry compatible connector
